Google Cloud Dataflow is a fully managed service for executing Apache Beam pipelines within the Google Cloud Platform ecosystem. Dataflow provides a fully managed service for executing Apache Beam pipelines, offering features like autoscaling, dynamic work rebalancing, and a managed execution environment. Dataflow is suitable for large-scale, continuous data processing jobs, and is one of the major components of Google's big data architecture on the Google Cloud Platform. At its core, Dataflow's architecture is designed to abstract away infrastructure management, allowing developers to focus purely on the logic of their data processing tasks. When a pipeline written using the Apache Beam SDK is submitted, Dataflow translates this high-level definition into an optimized job graph. The service then provisions and manages a fleet of Google Compute Engine workers to execute this graph in a highly parallelized and fault-tolerant manner. This serverless approach, combined with intelligent autoscaling of both the number of workers (horizontal) and the resources per worker (vertical), ensures that jobs have the precise amount of computational power needed at any given time, optimizing both performance and cost. The service's deep integration with the Google Cloud ecosystem makes it a powerful tool for a variety of use cases beyond simple data movement. For real-time analytics, Dataflow can ingest unbounded streams of data from Cloud Pub/Sub, perform complex transformations, and load results into BigQuery for immediate querying. In machine learning workflows, it is commonly used to preprocess and transform massive datasets stored in Cloud Storage, preparing them for training models in Vertex AI. This versatility makes it the central processing engine for modern ETL (Extract, Transform, Load) operations, streaming analytics, and large-scale data preparation within the cloud. == History == Google Cloud Dataflow was announced in June, 2014 and released to the general public as an open beta in April, 2015. In January, 2016 Google donated the underlying SDK, the implementation of a local runner, and a set of IOs (data connectors) to access Google Cloud Platform data services to the Apache Software Foundation. The donated code formed the original basis for Apache Beam. In August 2022, there was an incident where user timers were broken for certain Dataflow streaming pipelines in multiple regions, which was later resolved. Throughout 2023 and 2024, there have been various other updates and incidents affecting Google Cloud Dataflow, as documented in the release notes and service health history. The donation of the Dataflow SDK to the Apache Software Foundation was a pivotal moment, establishing Apache Beam as a unified, open-source programming model for defining both batch and streaming data pipelines. This strategic move decoupled the pipeline definition from the execution engine. As a result, developers could write portable data processing logic that was not locked into Google's ecosystem. A Beam pipeline can be executed on various runners, including Apache Flink, Apache Spark, and, of course, the highly optimized Google Cloud Dataflow service, providing flexibility and future-proofing data processing investments. == Features == Google Cloud Dataflow supports both batch and streaming data processing pipelines. It automatically handles resource provisioning, data sharding, and scaling according to workload, reducing manual configuration needed for large-scale data operations. == Use cases == Dataflow is used for ETL (Extract, Transform, Load) data pipelines, real-time analytics, and event stream processing for companies in industries such as finance, advertising, and IoT.
Shape context
Shape context is a feature descriptor used in object recognition. Serge Belongie and Jitendra Malik proposed the term in their paper "Matching with Shape Contexts" in 2000. == Theory == The shape context is intended to be a way of describing shapes that allows for measuring shape similarity and the recovering of point correspondences. The basic idea is to pick n points on the contours of a shape. For each point pi on the shape, consider the n − 1 vectors obtained by connecting pi to all other points. The set of all these vectors is a rich description of the shape localized at that point but is far too detailed. The key idea is that the distribution over relative positions is a robust, compact, and highly discriminative descriptor. So, for the point pi, the coarse histogram of the relative coordinates of the remaining n − 1 points, h i ( k ) = # { q ≠ p i : ( q − p i ) ∈ bin ( k ) } {\displaystyle h_{i}(k)=\#\{q\neq p_{i}:(q-p_{i})\in {\mbox{bin}}(k)\}} is defined to be the shape context of p i {\displaystyle p_{i}} . The bins are normally taken to be uniform in log-polar space. The fact that the shape context is a rich and discriminative descriptor can be seen in the figure below, in which the shape contexts of two different versions of the letter "A" are shown. (a) and (b) are the sampled edge points of the two shapes. (c) is the diagram of the log-polar bins used to compute the shape context. (d) is the shape context for the point marked with a circle in (a), (e) is that for the point marked as a diamond in (b), and (f) is that for the triangle. As can be seen, since (d) and (e) are the shape contexts for two closely related points, they are quite similar, while the shape context in (f) is very different. For a feature descriptor to be useful, it needs to have certain invariances. In particular it needs to be invariant to translation, scaling, small perturbations, and, depending on the application, rotation. Translational invariance comes naturally to shape context. Scale invariance is obtained by normalizing all radial distances by the mean distance α {\displaystyle \alpha } between all the point pairs in the shape although the median distance can also be used. Shape contexts are empirically demonstrated to be robust to deformations, noise, and outliers using synthetic point set matching experiments. One can provide complete rotational invariance in shape contexts. One way is to measure angles at each point relative to the direction of the tangent at that point (since the points are chosen on edges). This results in a completely rotationally invariant descriptor. But of course this is not always desired since some local features lose their discriminative power if not measured relative to the same frame. Many applications in fact forbid rotational invariance e.g. distinguishing a "6" from a "9". == Use in shape matching == A complete system that uses shape contexts for shape matching consists of the following steps (which will be covered in more detail in the Details of Implementation section): Randomly select a set of points that lie on the edges of a known shape and another set of points on an unknown shape. Compute the shape context of each point found in step 1. Match each point from the known shape to a point on an unknown shape. To minimize the cost of matching, first choose a transformation (e.g. affine, thin plate spline, etc.) that warps the edges of the known shape to the unknown (essentially aligning the two shapes). Then select the point on the unknown shape that most closely corresponds to each warped point on the known shape. Calculate the "shape distance" between each pair of points on the two shapes. Use a weighted sum of the shape context distance, the image appearance distance, and the bending energy (a measure of how much transformation is required to bring the two shapes into alignment). To identify the unknown shape, use a nearest-neighbor classifier to compare its shape distance to shape distances of known objects. == Details of implementation == === Step 1: Finding a list of points on shape edges === The approach assumes that the shape of an object is essentially captured by a finite subset of the points on the internal or external contours on the object. These can be simply obtained using the Canny edge detector and picking a random set of points from the edges. Note that these points need not and in general do not correspond to key-points such as maxima of curvature or inflection points. It is preferable to sample the shape with roughly uniform spacing, though it is not critical. === Step 2: Computing the shape context === This step is described in detail in the Theory section. === Step 3: Computing the cost matrix === Consider two points p and q that have normalized K-bin histograms (i.e. shape contexts) g(k) and h(k). As shape contexts are distributions represented as histograms, it is natural to use the χ2 test statistic as the "shape context cost" of matching the two points: C S = 1 2 ∑ k = 1 K [ g ( k ) − h ( k ) ] 2 g ( k ) + h ( k ) {\displaystyle C_{S}={\frac {1}{2}}\sum _{k=1}^{K}{\frac {[g(k)-h(k)]^{2}}{g(k)+h(k)}}} The values of this range from 0 to 1. In addition to the shape context cost, an extra cost based on the appearance can be added. For instance, it could be a measure of tangent angle dissimilarity (particularly useful in digit recognition): C A = 1 2 ‖ ( cos ( θ 1 ) sin ( θ 1 ) ) − ( cos ( θ 2 ) sin ( θ 2 ) ) ‖ {\displaystyle C_{A}={\frac {1}{2}}{\begin{Vmatrix}{\dbinom {\cos(\theta _{1})}{\sin(\theta _{1})}}-{\dbinom {\cos(\theta _{2})}{\sin(\theta _{2})}}\end{Vmatrix}}} This is half the length of the chord in unit circle between the unit vectors with angles θ 1 {\displaystyle \theta _{1}} and θ 2 {\displaystyle \theta _{2}} . Its values also range from 0 to 1. Now the total cost of matching the two points could be a weighted-sum of the two costs: C = ( 1 − β ) C S + β C A {\displaystyle C=(1-\beta )C_{S}+\beta C_{A}\!\,} Now for each point pi on the first shape and a point qj on the second shape, calculate the cost as described and call it Ci,j. This is the cost matrix. === Step 4: Finding the matching that minimizes total cost === Now, a one-to-one matching π ( i ) {\displaystyle \pi (i)} that matches each point pi on shape 1 and qj on shape 2 that minimizes the total cost of matching, H ( π ) = ∑ i C ( p i , q π ( i ) ) {\displaystyle H(\pi )=\sum _{i}C\left(p_{i},q_{\pi (i)}\right)} is needed. This can be done in O ( N 3 ) {\displaystyle O(N^{3})} time using the Hungarian method, although there are more efficient algorithms. To have robust handling of outliers, one can add "dummy" nodes that have a constant but reasonably large cost of matching to the cost matrix. This would cause the matching algorithm to match outliers to a "dummy" if there is no real match. === Step 5: Modeling transformation === Given the set of correspondences between a finite set of points on the two shapes, a transformation T : R 2 → R 2 {\displaystyle T:\mathbb {R} ^{2}\to \mathbb {R} ^{2}} can be estimated to map any point from one shape to the other. There are several choices for this transformation, described below. ==== Affine ==== The affine model is a standard choice: T ( p ) = A p + o {\displaystyle T(p)=Ap+o\!} . The least squares solution for the matrix A {\displaystyle A} and the translational offset vector o is obtained by: o = 1 n ∑ i = 1 n ( p i − q π ( i ) ) , A = ( Q + P ) t {\displaystyle o={\frac {1}{n}}\sum _{i=1}^{n}\left(p_{i}-q_{\pi (i)}\right),A=(Q^{+}P)^{t}} Where P = ( 1 p 11 p 12 ⋮ ⋮ ⋮ 1 p n 1 p n 2 ) {\displaystyle P={\begin{pmatrix}1&p_{11}&p_{12}\\\vdots &\vdots &\vdots \\1&p_{n1}&p_{n2}\end{pmatrix}}} with a similar expression for Q {\displaystyle Q\!} . Q + {\displaystyle Q^{+}\!} is the pseudoinverse of Q {\displaystyle Q\!} . ==== Thin plate spline ==== The thin plate spline (TPS) model is the most widely used model for transformations when working with shape contexts. A 2D transformation can be separated into two TPS function to model a coordinate transform: T ( x , y ) = ( f x ( x , y ) , f y ( x , y ) ) {\displaystyle T(x,y)=\left(f_{x}(x,y),f_{y}(x,y)\right)} where each of the ƒx and ƒy have the form: f ( x , y ) = a 1 + a x x + a y y + ∑ i = 1 n ω i U ( ‖ ( x i , y i ) − ( x , y ) ‖ ) , {\displaystyle f(x,y)=a_{1}+a_{x}x+a_{y}y+\sum _{i=1}^{n}\omega _{i}U\left({\begin{Vmatrix}(x_{i},y_{i})-(x,y)\end{Vmatrix}}\right),} and the kernel function U ( r ) {\displaystyle U(r)\!} is defined by U ( r ) = r 2 log r 2 {\displaystyle U(r)=r^{2}\log r^{2}\!} . The exact details of how to solve for the parameters can be found elsewhere but it essentially involves solving a linear system of equations. The bending energy (a measure of how much transformation is needed to align the points) will also be easily obtained. ==== Regularized TPS ==== The TPS formulation above has exact matching requirement for the pairs of points on the two shapes. For noisy data, it is best to
Cepstral mean and variance normalization
Cepstral mean and variance normalization (CMVN) is a computationally efficient normalization technique for robust speech recognition. The performance of CMVN is known to degrade for short utterances. This is due to insufficient data for parameter estimation and loss of discriminable information as all utterances are forced to have zero mean and unit variance. CMVN minimizes distortion by noise contamination for robust feature extraction by linearly transforming the cepstral coefficients to have the same segmental statistics. Cepstral Normalization has been effective in the CMU Sphinx for maintaining a high level of recognition accuracy over a wide variety of acoustical environments. == Cepstral Normalization Techniques == There are multiple algorithms that achieve Cepstral Normalization in different ways. === Fixed codeword-dependent cepstral normalization (FCDCN) === FCDCN was developed to provide a form of compensation that provides greater recognition accuracy than SDCN but in a more computationally-efficient manner than the CDCN algorithm. The FCDCN algorithm applies an additive correction that depends on the instantaneous SNR of the input (like SDCN), but that can also vary from codeword to codeword (like CDCN). === Multiple Fixed Codeword-dependent Cepstral Normalization (MFCDCN) === MFCDCN is a simple extension of FCDCN algorithm that does not need environment specific training. In MFCDCN, compensation vectors are pre-computed in parallel for a set of target environments, using the FCDCN algorithm. === Incremental Multiple Fixed Codeword-dependent Cepstral Normalization (IMFCDCN) === While environment selection for the compensation vectors of MFCDCN is generally performed on an utterance-by-utterance basis, IMFCFCN improves on it by allowing the classification process to make use of cepstral vectors from previous utterances in a given session. == Cepstral Noise Subtraction == Automatic speech recognition (ASR) describes the steps of transcribing speech utterances represented as acoustic wave forms to written words. As is, CMVN has been used in different applications as this technique has proven to provide better speech recognitions results in different environments. CMVN has the capabilities to reduce differences between test and training data produced by channel distortions and colorizations . CMVN has also been found to be able to reduce differences in feature representation between speakers can also partly reduce the influence of background noise.
Projection-slice theorem
In mathematics, the projection-slice theorem, central slice theorem or Fourier slice theorem in two dimensions states that the results of the following two calculations are equal: Take a two-dimensional function f(r), project (e.g. using the Radon transform) it onto a (one-dimensional) line, and do a Fourier transform of that projection. Take that same function, but do a two-dimensional Fourier transform first, and then slice the function through its origin, parallel to the projection line. In operator terms, if F1 and F2 are the 1- and 2-dimensional Fourier transform operators mentioned above, P1 is the projection operator (which projects a 2-D function onto a 1-D line), S1 is a slice operator (which extracts a 1-D central slice from a function), then F 1 P 1 = S 1 F 2 . {\displaystyle F_{1}P_{1}=S_{1}F_{2}.} This idea can be extended to higher dimensions. This theorem is used, for example, in the analysis of medical CT scans where a "projection" is an x-ray image of an internal organ. The Fourier transforms of these images are seen to be slices through the Fourier transform of the 3-dimensional density of the internal organ, and these slices can be interpolated to build up a complete Fourier transform of that density. The inverse Fourier transform is then used to recover the 3-dimensional density of the object. This technique was first derived by Ronald N. Bracewell in 1956 for a radio-astronomy problem. == The projection-slice theorem in N dimensions == In N dimensions, the projection-slice theorem states that the Fourier transform of the projection of an N-dimensional function f(r) onto an m-dimensional linear submanifold is equal to an m-dimensional slice of the N-dimensional Fourier transform of that function consisting of an m-dimensional linear submanifold through the origin in the Fourier space which is parallel to the projection submanifold. In operator terms: F m P m = S m F N . {\displaystyle F_{m}P_{m}=S_{m}F_{N}.\,} == The generalized Fourier-slice theorem == In addition to generalizing to N dimensions, the projection-slice theorem can be further generalized with an arbitrary change of basis. For convenience of notation, we consider the change of basis to be represented as B, an N-by-N invertible matrix operating on N-dimensional column vectors. Then the generalized Fourier-slice theorem can be stated as F m P m B = S m B − T | B − T | F N {\displaystyle F_{m}P_{m}B=S_{m}{\frac {B^{-T}}{|B^{-T}|}}F_{N}} where B − T = ( B − 1 ) T {\displaystyle B^{-T}=(B^{-1})^{T}} is the transpose of the inverse of the change of basis transform. == Proof in two dimensions == The projection-slice theorem is easily proven for the case of two dimensions. Without loss of generality, we can take the projection line to be the x-axis. There is no loss of generality because if we use a shifted and rotated line, the law still applies. Using a shifted line (in y) gives the same projection and therefore the same 1D Fourier transform results. The rotated function is the Fourier pair of the rotated Fourier transform, for which the theorem again holds. If f(x, y) is a two-dimensional function, then the projection of f(x, y) onto the x axis is p(x) where p ( x ) = ∫ − ∞ ∞ f ( x , y ) d y . {\displaystyle p(x)=\int _{-\infty }^{\infty }f(x,y)\,dy.} The Fourier transform of f ( x , y ) {\displaystyle f(x,y)} is F ( k x , k y ) = ∫ − ∞ ∞ ∫ − ∞ ∞ f ( x , y ) e − 2 π i ( x k x + y k y ) d x d y . {\displaystyle F(k_{x},k_{y})=\int _{-\infty }^{\infty }\int _{-\infty }^{\infty }f(x,y)\,e^{-2\pi i(xk_{x}+yk_{y})}\,dxdy.} The slice is then s ( k x ) {\displaystyle s(k_{x})} s ( k x ) = F ( k x , 0 ) = ∫ − ∞ ∞ ∫ − ∞ ∞ f ( x , y ) e − 2 π i x k x d x d y {\displaystyle s(k_{x})=F(k_{x},0)=\int _{-\infty }^{\infty }\int _{-\infty }^{\infty }f(x,y)\,e^{-2\pi ixk_{x}}\,dxdy} = ∫ − ∞ ∞ [ ∫ − ∞ ∞ f ( x , y ) d y ] e − 2 π i x k x d x {\displaystyle =\int _{-\infty }^{\infty }\left[\int _{-\infty }^{\infty }f(x,y)\,dy\right]\,e^{-2\pi ixk_{x}}dx} = ∫ − ∞ ∞ p ( x ) e − 2 π i x k x d x {\displaystyle =\int _{-\infty }^{\infty }p(x)\,e^{-2\pi ixk_{x}}dx} which is just the Fourier transform of p(x). The proof for higher dimensions is easily generalized from the above example. == The FHA cycle == If the two-dimensional function f(r) is circularly symmetric, it may be represented as f(r), where r = |r|. In this case the projection onto any projection line will be the Abel transform of f(r). The two-dimensional Fourier transform of f(r) will be a circularly symmetric function given by the zeroth-order Hankel transform of f(r), which will therefore also represent any slice through the origin. The projection-slice theorem then states that the Fourier transform of the projection equals the slice or F 1 A 1 = H , {\displaystyle F_{1}A_{1}=H,} where A1 represents the Abel-transform operator, projecting a two-dimensional circularly symmetric function onto a one-dimensional line, F1 represents the 1-D Fourier-transform operator, and H represents the zeroth-order Hankel-transform operator. == Extension to fan beam or cone-beam CT == The projection-slice theorem is suitable for CT image reconstruction with parallel beam projections. It does not directly apply to fanbeam or conebeam CT. The theorem was extended to fan-beam and conebeam CT image reconstruction by Shuang-ren Zhao in 1995.
Quantum robotics
Quantum robotics is an interdisciplinary field that investigates the intersection of robotics and quantum mechanics. This field, in particular, explores the applications of quantum phenomena such as quantum entanglement within the realm of robotics. Examples of its applications include quantum communication in multi-agent cooperative robotic scenarios, the use of quantum algorithms in performing robotics tasks, and the integration of quantum devices (e.g., quantum detectors) in robotic systems. == Introduction == The free-space quantum communication between mobile platforms was proposed for reconfigurable quantum key distribution (QKD) applications using unmanned aerial vehicle (UAVs, a.k.a. drones) in 2017. This technology was later advanced in various aspects in mobile drone and vehicle platforms in several configurations such as drone-to-drone, drone-to-moving vehicle, and vehicle-to-vehicle systems. Some research has contributed to low-size, low-weight, and low-power quantum key distribution systems for small-form UAVs, the characterization of a polarization-based receiver for mobile free-space optical QKD, and optical-relayed entanglement distribution using drones as mobile nodes. The topic of free-space quantum communication between mobile platforms, initially developed to meet the need for free-space QKD and entanglement distribution using mobile nodes, was brought into the robotics domain as an emerging interdisciplinary mechatronics topic to investigate the interface between quantum technologies and the robotic systems domain. The main advantage of such integrated technology is the guaranteed security in communication between multi-agent and cooperative autonomous systems. Other advances are anticipated. == Quantum entanglement == According to quantum mechanics, entanglement occurs when more than one particle become connected. If the state of one particle changes then it will instantly change the state of other particles regardless of their distance. Entangled sensors do the same kind of work and achieve strong sensitivity. A group of quantum robots can measure magnetic fields, gravitational fields and other physical properties using entangled sensors with high rate of accuracy. Again the connection of one robot to other is increased (become strong) by quantum entanglement. == Quantum teleportation == Quantum teleportation is the transfer of quantum information (not physical objects). This is used in case of multi robot process. One robot is programmed with a complex quantum update. Then that robot can teleport that complex quantum information (the update) to other robots. This teleportation or communication is very secure because all the work is done in quantum state. == Kinematics == Quantum computing has been proposed as being optimal for calculating inverse kinematics values. == Alice and Bob robots == In the realm of quantum mechanics, the names Alice and Bob are frequently employed to illustrate various phenomena, protocols, and applications. These include their roles in QKD, quantum cryptography, entanglement, and teleportation. The terms "Alice Robot" and "Bob Robot" serve as analogous expressions that merge the concepts of Alice and Bob from quantum mechanics with mechatronic mobile platforms (such as robots, drones, and autonomous vehicles). For example, the Alice Robot functions as a transmitter platform that communicates with the Bob Robot, housing the receiving detectors.
Foundry VTT
Foundry Virtual Tabletop, commonly shortened to Foundry VTT or FVTT, is a commercial, self-hosted virtual tabletop application for role-playing games. It provides a stage for visualizing the game environment and tools allowing the game master and players to organize and track statistics and notes. The software is highly modular and depends on the community-maintained ecosystem of add-on modules that modify the software's behavior and implement different game systems. Perpetual licenses, which include updates, are offered for a one-time fee. == Features == Foundry Virtual Tabletop is a highly modular Node.js web application that is run locally by the Gamemaster or hosted on a remote server. Players connect to their gamemaster's Foundry VTT instance over the network using their web browser. It is system-agnostic in that its core feature-set is not restricted to a specific game system. Systems, specific features and game content are implemented as add-on modules, which can be individually downloaded from a public repository. The module repository contains paid, official content, as well as freely available community-made modules that enhance functionality of the software. As of May 2025, 350 individual game systems are implemented as modules. Individual settings created by the Game Master are termed Worlds in the interface and contain the list of modules that should be loaded as well as world-specific content, which can be added by the gamemaster. This content is grouped into Scenes, Actors, Items and Journals. Battle and world maps are created as Scenes, which contain the backdrop and data on placement of walls, light sources and other entities. Tokens representing Actors, which are player characters, vehicles or NPCs, can be placed on these Scenes to be moved by the user that owns them. Other entities that interact or integrate with actors are termed Items; these can be objects, but also game system-specific concepts such as character classes. Journals are text documents that can link to other entities present in the World or modules. Viewing and editing permissions can be set individually for each entity. The software features a custom lighting engine that determines visibility of certain areas on each battle map depending on the position of players' characters, also revealing areas covered by fog of war. It also contains tools for map creation and comes with a small asset library. == History == Foundry Gaming LLC founder Andrew Clayton, commonly known under his online nickname Atropos, began development of Foundry VTT in 2018 for personal use after becoming dissatisfied with the feature set and business models of other virtual tabletops. Foundry VTT was initially developed for Linux, which remains its primary platform, with support for other platforms having been developed later. Foundry Gaming LLC was incorporated in Spokane, Washington on October 9, 2018, with the software remaining in private beta-testing until May 2020, when it was publicly released. In November 2020, Cubicle 7 partnered with Foundry to bring official content modules for its game system Warhammer Fantasy Roleplay to Foundry VTT. Later, in 2025, Clayton would state that this first major publisher deal was of significant importance to Foundry VTT's growth and credits the community developers of the WFRP system module for making it possible in the first place. In November 2023, Paizo partnered with Foundry to bring official content modules for Pathfinder Roleplaying Game to Foundry VTT. In January 2024, Foundry publicly announced its partnership with Wizards of the Coast in bringing official Dungeons & Dragons content to Foundry VTT, with the first official module, Phandelver and Below: The Shattered Obelisk, having been released in February 2024. == Development == As of 2023, the Foundry VTT software itself is being developed and managed by a team of 9 people, while a content team of 12 people is working with partnered publishers to compile content into downloadable modules. The content team also develops in-house content published by Foundry Gaming LLC. Stated goals are to create a virtual tabletop software that offers a one-time purchase and content ownership, make use of modern web technologies, and provide a platform for developers to build upon. Clayton has stated that integration of Generative AI into Foundry VTT is not planned, citing ethical and legal concerns and calling its usage within the industry a "betrayal of the creative people who made the TTRPG industry what it is in the first place". == Reception == Foundry VTT is one of the most popular virtual tabletops for TTRPGs; in particular, as a self-hosted web-based VTT, it is known as a modern alternative to the software as a service Roll20. Wargamer named it one of the three "best virtual tabletops for D&D in 2023", noting its active community and high degree of technical complexity, which allows for customization not seen in other products at the cost of a much steeper learning curve. Comic Book Resources called it an "underrated gem" and "incredibly versatile" for similar reasons, while also praising its lighting engine and visual fidelity. As the previously mentioned outlets do, Foundry's modular ecosystem and technical implementation are often mentioned as good features, but also as a source of frustration for new users. In a video interview, Clayton acknowledges this issue and affirms that the development team intends to make usage of more technical features "friction-less" and will reduce module breakage between updates in the future.
Scan line
A scan line (also scanline) is one line, or row, in a raster scanning pattern, such as a line of video on a cathode-ray tube (CRT) display of a television set or computer monitor. On CRT screens the horizontal scan lines are visually discernible, even when viewed from a distance, as alternating colored lines and black lines, especially when a progressive scan signal with below maximum vertical resolution is displayed. This is sometimes used today as a visual effect in computer graphics. The term is used, by analogy, for a single row of pixels in a raster graphics image. Scan lines are important in representations of image data, because many image file formats have special rules for data at the end of a scan line. For example, there may be a rule that each scan line starts on a particular boundary (such as a byte or word; see for example BMP file format). This means that even otherwise compatible raster data may need to be analyzed at the level of scan lines in order to convert between formats.
